Basic Info.
Model NO.
MKC-N15
Coating
Black Epoxy, Ni-Cu-Ni, Zn, etc
Grade
N28UH-N40UH
Function
for Indcution, Fixator, Magnetic Field Research
Size
Customized Size
Color
Black and Silvery or Customized
Material
Nedoyminum/Ferrite Magnet and Steel
Transport Package
Standard Sea or Air Package, Will Be Protected We
Specification
Customized
Trademark
MKC
Origin
China
HS Code
8505111000
Production Capacity
500000pieces/Year
Product Description
| Product name | Neodymium iron boron permanent magnets with various performance shapes, sizes, and coating options can be customized |
| Place of Origin | Chian Zhejiang |
| Brand Name | Neodymium Magnet |
| Size | Customized Size |
| Coating | Black Epoxy,Ni-Cu-Ni,Zn,etc |
| Material | Nedoyminum |
| TYPICAL PROPERTY | |||||
| MAGNETIC CHARACTERISTICS | |||||
| PROPERTIES | BrmT (KGs) | Hcb KA/m (Koe) | Hcj KA/m (KOe) | (BH)max KJ/m³ (MGOe) | Max.TW ºC |
| GRADE | |||||
| N33 | 1130-1170 (11.3-11.7) | ≥836 (≥10.5) | ≥955 (≥12) | 247-263 (31-33) | 80 |
| N35 | 1170-1210 (11.7-12.1) | ≥868 (≥10.9) | ≥955 (≥12) | 263-287 (33-36) | 80 |
| N38 | 1210-1250 (12.1-12.5) | ≥899 (≥11.3) | ≥955 (≥12) | 287-310 (36-39) | 80 |
| N40 | 1250-1280 (12.5-12.8) | ≥923 (≥11.6) | ≥955 (≥12) | 302-326 (38-41) | 80 |
| N42 | 1280-1320 (12.8-13.2) | ≥923 (≥11.6) | ≥955 (≥12) | 318-342 (40-43) | 80 |
| N45 | 1320-1380 (13.2-13.8) | ≥876 (≥11.0) | ≥955 (≥12) | 342-366 (43-46) | 80 |
| N48 | 1380-1420 (13.8-14.2) | ≥835 (≥10.5) | ≥876 (≥11) | 366-390 (46-49) | 80 |
| N50 | 1400-1450 (14.0-14.5) | ≥796 (≥10.0) | ≥876 (≥11) | 382-406 (48-51) | 60 |
| N52 | 1430-1480 (14.3-14.8) | ≥796 (≥10.0) | ≥876 (≥11) | 398-422 (50-53) | 60 |
| N35M | 1170-1220 (11.7-12.2) | ≥868 (≥10.9) | ≥1114 (≥14) | 263-287 (33-36) | 100 |
| N38M | 1220-1250 (12.2-12.5) | ≥899 (≥11.3) | ≥1114 (≥14) | 287-310 (36-39) | 100 |
| N40M | 1250-1280 (12.5-12.8) | ≥923 (≥11.6) | ≥1114 (≥14) | 302-326 (38-41) | 100 |
| N42M | 1280-1320 (12.8-13.2) | ≥955 (≥12.0) | ≥1114 (≥14) | 318-342 (40-43) | 100 |
| N45M | 1320-1380 (13.2-13.8) | ≥995 (≥12.5) | ≥1114 (≥14) | 342-366 (43-46) | 100 |
| N48M | 1360-1430 (13.6-14.3) | ≥1027 (≥12.9) | ≥1114 (≥14) | 366-390 (46-49) | 100 |
| N50M | 1400-1450 (14.0-14.5) | ≥1033 (≥13.0) | ≥1114 (≥14) | 382-406 (48-51) | 100 |
| 33H | 1130-1170 (11.3-11.7) | ≥836 (≥10.5) | ≥1353 (≥17) | 247-271 (31-34) | 120 |
| 35H | 1170-1210 (11.7-12.1) | ≥868 (≥10.9) | ≥1353 (≥17) | 263-287 (33-36) | 120 |
| 38H | 1210-1250 (12.1-12.5) | ≥899 (≥11.3) | ≥1353 (≥17) | 287-310 (36-39) | 120 |
| 40H | 1240-1280 (12.4-12.8) | ≥923 (≥11.6) | ≥1353 (≥17) | 302-326 (38-41) | 120 |
| 42H | 1280-1320 (12.8-13.2) | ≥955 (≥12.0) | ≥1353 (≥17) | 318-342 (40-43) | 120 |
| 45H | 1300-1360 (13.0-13.6) | ≥963 (≥12.1) | ≥1353 (≥17) | 342-358 (43-46) | 120 |
| 48H | 1370-1430 (13.7-14.3) | ≥995 (≥12.5) | ≥1353 (≥17) | 358-390 (46-49) | 120 |
| 33SH | 1130-1170 (11.3-11.7) | ≥844 (≥10.6) | ≥1592 (≥20) | 247-272 (31-34) | 150 |
| 35SH | 1170-1210 (11.7-12.1) | ≥876 (≥11.0) | ≥1592 (≥20) | 263-287 (33-36) | 150 |
| 38SH | 1210-1250 (12.1-12.5) | ≥907 (≥11.4) | ≥1592 (≥20) | 287-310 (36-39) | 150 |
| 40SH | 1240-1280 (12.4-12.8) | ≥939 (≥11.8) | ≥1592 (≥20) | 302-326 (38-41) | 150 |
| 42SH | 1280-1320 (12.8-13.2) | ≥987 (≥12.4) | ≥1592 (≥20) | 318-342 (40-43) | 150 |
| 45SH | 1320-1380 (13.2-13.8) | ≥1003 (≥12.6) | ≥1592 (≥20) | 342-366 (43-46) | 150 |
| 28UH | 1020-1080 (10.2-10.8) | ≥764 (≥9.6) | ≥1990 (≥25) | 207-231 (26-29) | 180 |
| 30UH | 1080-1130 (10.8-11.3) | ≥812 (≥10.2) | ≥1990 (≥25) | 223-247 (28-31) | 180 |
| 33UH | 1130-1170 (11.3-11.7) | ≥852 (≥10.7) | ≥1990 (≥25) | 247-271 (31-34) | 180 |
| 35UH | 1180-1220 (11.8-12.2) | ≥860 (≥10.8) | ≥1990 (≥25) | 263-287 (33-36) | 180 |
| 38UH | 1220-1250 (12.2-12.5) | ≥876 (≥11.0) | ≥1990 (≥25) | 287-310 (36-39) | 180 |
| 40UH | 1240-1280 (12.4-12.8) | ≥899 (≥11.3) | ≥1990 (≥25) | 302-326 (38-41) | 180 |
| 28EH | 1040-1090 (10.4-10.9) | ≥780 (≥9.8) | ≥2388 (≥30) | 207-231 (26-29) | 200 |
| 30EH | 1080-1130 (10.8-11.3) | ≥812 (≥10.2) | ≥2388 (≥30) | 223-247 (28-31) | 200 |
| 33EH | 1130-1170 (11.3-11.7) | ≥836 (≥10.5) | ≥2388 (≥30) | 247-271 (31-34) | 200 |
| 35EH | 1170-1220 (11.7-12.2) | ≥876 (≥11.0) | ≥2388 (≥30) | 263-287 (33-36) | 200 |
| 38EH | 1220-1250 (12.2-12.5) | ≥899 (≥11.3) | ≥2388 (≥30) | 287-310 (36-39) | <=200 |
